- CPU
- Rockchip RK3568, Quad-core A55, 2.0 GHz
|
- System memory
- DDR4 4GB
|
- Storage
- eMMC 32GB(eMMC 64GB, optional)
|
- Multi-Media
- Support 1080P, H.265 hardware decoder
|
- Operation System
- Android 11
|
- Network
- AzureWave /Ampack /AW-CM390SM (support to BT5.3)
Wi-Fi 802.11 AC 2.4/5GHz
|
- Playback
- wmv, avi, flv, rm, rmvb, mpeg , ts, mp4
|
- Graphics
- BMP, JPEG, PNG, GIF
|
- Display
- 12.2″ LED Backlight (1920×1200 / 16:10 Ratio / 350cd/m² (Typ)) / PCAP 10 Point Multi-touch
|
- Secondary Display
- 8” Customer Display / LED Backlight (1280×800 / 16:10 Ratio / 270cd/m² (Typ)) / PCAP 10 Point Multi-touch
|
- USB
- USB 3.0 x 2 (External x 1, type C x 1)
USB 2.0 x 3 (External x 2, RJ11 x 1)
|
- LAN
- RJ45 x 1(Base-T 10,100,1000m/bps Ethernet)
|
- Serial port
- RJ50 x 1, RJ11 x 1
|
- Audio
- Audio-out / 3.5mm x 1
|
- Speaker
- 3W x 1
|
- RTC clock
- RTC clock battery on board
|
- Dimension (W x D x H)
- 292 x 383 x 106 (mm)
|
- Weight
- 3.4 kg
|
- Power input
- Type C (60W) 12V/5A ; support PD
|
- Temperature
- Operating Temp : 0~40℃ / Storage Temp : -20~60℃
Humidity : 20~90%H non-condensing
|
- Certifications
- CE, FCC, KC
|
